Selected model: OPPO CPH2179 (OPPO A15s)
Operation: Flash (Download only)
Software version: 9.1
Parse scatter file... OK
Load Rom Images... OK
Connect Type-C to NONE... OK
Host Power Off... OK
Connect phone to [PC] in BROM/PRELOADER Mode
Waiting for device... OK
Driver: [MediaTek Inc.,wdm_usb,MediaTek USB Port_V1632,usb2ser.sys,3.0.1504.0]
Device found at COM50 [BROM]
Open port... OK
Send start cmd... OK
Get HW code from device... 0766
Get sec config... OK [000000E5]
Active sec flags: [SBC DAA]
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
LibUSB installed
Library Version [2]
Select platform... OK
Init BROM... OK
Force Charge... OK
Disable WatchDog Timer... OK
Release testpoint, waiting 2 seconds
Advanced Bypass Security... OK
Waiting for device... OK
Driver: [MediaTek Inc.,wdm_usb,MediaTek USB Port_V1632,usb2ser.sys,3.0.1504.0]
Device found at COM50 [BROM]
Open port... OK
Send start cmd... OK
Get HW code from device... 0766
Get sec config... OK [000000E0]
Active sec flags: []
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
Library Version [2]
Select platform... OK
Init BROM... OK
Force Charge... OK
Disable WatchDog Timer... OK
Reopen port for libver2... OK
Get ME ID... OK
ME_ID = 0x267FF064, 0x00F969CA, 0x2B002D97, 0xFA4F9EB4
Get Chip ID... [MT6765]
Get SOC ID... [2FE10AC5D005C49373C3A65109C24FBE7DE286C8015767A2C49C31D57EBF6D06]
Get sec config... OK [000000E0]
Load DownloadAgent... OK
Search DA... OK [7]
Send preloader... OK
Start preloader... OK
Checking preloader answer... OK
Send bootloader... OK
Start bootloader... OK
Wait for answer from bootloader... OK
Send SYNC signal... OK
Setup device enviroment... OK
Setup device parametres... OK
Receive DA SYNC signal... OK
Set DA parametres... OK
Get device connection agent... [BROM]
Get device info... OK
EMMC_ID: 0x150100444836444142027904C4B1C541
Load EMI config from preloader... OK
Init EXT RAM... OK
Send 2nd DA... OK
Get device info... OK
EMMC INFO:
EMMC_CNAME: DH6DAB
EMMC_ID : 0x150100444836444142027904C4B1C541
EMMC_BOOT1: 0x0000400000 (4.00Mb)
EMMC_BOOT2: 0x0000400000 (4.00Mb)
EMMC_RPMB : 0x0001000000 (16.00Mb)
EMMC_USER : 0x0E8F800000 (58.24Gb)
RAM INFO:
INT_SRAM: 0x000003A000 (232.00Kb)
EXT_RAM : 0x0100000000 (4.00Gb)
HEALTH:
Pre EOL Info: normal
DeviceLifeTimeEstA: 0% - 10% device life time used
DeviceLifeTimeEstB: 0% - 10% device life time used
Get scatter info... OK
Checking USB status... USB_HIGH_SPEED
Read partitions info from phone... OK
Checking A/B state... OK
Read product info... [EXT4] ... error(main\oppo_product(1.0))
Get scatter info... OK
Verify scatter file... OK
Do NAND BMT remark... OK
Setup download info... OK
Get partition table catagory... OK [GPT]
Read mirror partition table... OK
Checking partition table layout changed... OK
Read major partition table... OK
Checking major partition table layout changed... OK
Download "preloader"... OK
Download "recovery"... OK
Download "vbmeta_system"... OK
Download "vbmeta_vendor"... OK
Download "md1img"... OK
Download "spmfw"... OK
Download "scp1"... OK
Download "scp2"... OK
Download "sspm_1"... OK
Download "sspm_2"... OK
Download "lk"... OK
Download "lk2"... OK
Download "boot"... OK
Download "logo"... OK
Download "dtbo"... OK
Download "tee1"... OK
Download "tee2"... OK
Download "super"... OK
Download "vbmeta"... OK
Download "cache"... OK
Download "userdata"... OK
Flashing done!
Operation: Flash (Download only)
Software version: 9.1
Parse scatter file... OK
Load Rom Images... OK
Connect Type-C to NONE... OK
Host Power Off... OK
Connect phone to [PC] in BROM/PRELOADER Mode
Waiting for device... OK
Driver: [MediaTek Inc.,wdm_usb,MediaTek USB Port_V1632,usb2ser.sys,3.0.1504.0]
Device found at COM50 [BROM]
Open port... OK
Send start cmd... OK
Get HW code from device... 0766
Get sec config... OK [000000E5]
Active sec flags: [SBC DAA]
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
LibUSB installed
Library Version [2]
Select platform... OK
Init BROM... OK
Force Charge... OK
Disable WatchDog Timer... OK
Release testpoint, waiting 2 seconds
Advanced Bypass Security... OK
Waiting for device... OK
Driver: [MediaTek Inc.,wdm_usb,MediaTek USB Port_V1632,usb2ser.sys,3.0.1504.0]
Device found at COM50 [BROM]
Open port... OK
Send start cmd... OK
Get HW code from device... 0766
Get sec config... OK [000000E0]
Active sec flags: []
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
Library Version [2]
Select platform... OK
Init BROM... OK
Force Charge... OK
Disable WatchDog Timer... OK
Reopen port for libver2... OK
Get ME ID... OK
ME_ID = 0x267FF064, 0x00F969CA, 0x2B002D97, 0xFA4F9EB4
Get Chip ID... [MT6765]
Get SOC ID... [2FE10AC5D005C49373C3A65109C24FBE7DE286C8015767A2C49C31D57EBF6D06]
Get sec config... OK [000000E0]
Load DownloadAgent... OK
Search DA... OK [7]
Send preloader... OK
Start preloader... OK
Checking preloader answer... OK
Send bootloader... OK
Start bootloader... OK
Wait for answer from bootloader... OK
Send SYNC signal... OK
Setup device enviroment... OK
Setup device parametres... OK
Receive DA SYNC signal... OK
Set DA parametres... OK
Get device connection agent... [BROM]
Get device info... OK
EMMC_ID: 0x150100444836444142027904C4B1C541
Load EMI config from preloader... OK
Init EXT RAM... OK
Send 2nd DA... OK
Get device info... OK
EMMC INFO:
EMMC_CNAME: DH6DAB
EMMC_ID : 0x150100444836444142027904C4B1C541
EMMC_BOOT1: 0x0000400000 (4.00Mb)
EMMC_BOOT2: 0x0000400000 (4.00Mb)
EMMC_RPMB : 0x0001000000 (16.00Mb)
EMMC_USER : 0x0E8F800000 (58.24Gb)
RAM INFO:
INT_SRAM: 0x000003A000 (232.00Kb)
EXT_RAM : 0x0100000000 (4.00Gb)
HEALTH:
Pre EOL Info: normal
DeviceLifeTimeEstA: 0% - 10% device life time used
DeviceLifeTimeEstB: 0% - 10% device life time used
Get scatter info... OK
Checking USB status... USB_HIGH_SPEED
Read partitions info from phone... OK
Checking A/B state... OK
Read product info... [EXT4] ... error(main\oppo_product(1.0))
Get scatter info... OK
Verify scatter file... OK
Do NAND BMT remark... OK
Setup download info... OK
Get partition table catagory... OK [GPT]
Read mirror partition table... OK
Checking partition table layout changed... OK
Read major partition table... OK
Checking major partition table layout changed... OK
Download "preloader"... OK
Download "recovery"... OK
Download "vbmeta_system"... OK
Download "vbmeta_vendor"... OK
Download "md1img"... OK
Download "spmfw"... OK
Download "scp1"... OK
Download "scp2"... OK
Download "sspm_1"... OK
Download "sspm_2"... OK
Download "lk"... OK
Download "lk2"... OK
Download "boot"... OK
Download "logo"... OK
Download "dtbo"... OK
Download "tee1"... OK
Download "tee2"... OK
Download "super"... OK
Download "vbmeta"... OK
Download "cache"... OK
Download "userdata"... OK
Flashing done!
