Micromax Q413 Dead After Format With CM2 Recover Done With Easy Jtag



Setting interface to EasyJtag2/E-Socket
Setting bus width to 8 Bit
Setting frequence to 42 MHz
EMMC Device Information :
EMMC CID: 150100524531424D4207B415C6B56357
EMMC CSD: D02701320F5903FFF6DBFFEF8E40400D
EMMC Manufacture : SAMSUNG , EMMC NAME: RE1BMB , HEX: 524531424D42 , S/N: B415C6B5 , rev. 0x07
EMMC Manufacture ID: 0x15 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 6/2016
EMMC ROM 1 (Main User Data) Capacity: 14910 MB (0003A3E00000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: RE1BMB_B415C6B5_20190705_195832.extcsd
EMMC Init completed.

Scanning soft partitions
GPT header is found and is valid
Partition: proinfo, [000000080000 - 000000380000], size: 000000300000 (3.00 MB)
Partition: nvram, [000000380000 - 000000880000], size: 000000500000 (5.00 MB)
Partition: protect1, [000000880000 - 000001280000], size: 000000A00000 (10.0 MB)
Partition: protect2, [000001280000 - 000001C80000], size: 000000A00000 (10.0 MB)
Partition: lk, [000001C80000 - 000001D00000], size: 000000080000 (512. KB)
Partition: para, [000001D00000 - 000001D80000], size: 000000080000 (512. KB)
Partition: boot, [000001D80000 - 000002D80000], size: 000001000000 (16.0 MB)
Partition: recovery, [000002D80000 - 000003D80000], size: 000001000000 (16.0 MB)
Partition: logo, [000003D80000 - 000004580000], size: 000000800000 (8.00 MB)
Partition: expdb, [000004580000 - 000004F80000], size: 000000A00000 (10.0 MB)
Partition: seccfg, [000004F80000 - 000005000000], size: 000000080000 (512. KB)
Partition: oemkeystore, [000005000000 - 000005200000], size: 000000200000 (2.00 MB)
Partition: secro, [000005200000 - 000005800000], size: 000000600000 (6.00 MB)
Partition: keystore, [000005800000 - 000006000000], size: 000000800000 (8.00 MB)
Partition: tee1, [000006000000 - 000006500000], size: 000000500000 (5.00 MB)
Partition: tee2, [000006500000 - 000006A00000], size: 000000500000 (5.00 MB)
Partition: frp, [000006A00000 - 000006B00000], size: 000000100000 (1.00 MB)
Partition: nvdata, [000006B00000 - 000008B00000], size: 000002000000 (32.0 MB)
Partition: metadata, [000008B00000 - 00000B000000], size: 000002500000 (37.0 MB)
Partition: system, [00000B000000 - 00008B000000], size: 000080000000 (2.00 GB)
Partition: cache, [00008B000000 - 000093000000], size: 000008000000 (128. MB)
Partition: userdata, [000093000000 - 0003A2D80000], size: 00030FD80000 (12.2 GB)
Partition: flashinfo, [0003A2D80000 - 0003A3D80000], size: 000001000000 (16.0 MB)
GPT header successfully parsed

Get firmware version

Firmware info not found

Operation: Preloader parser

preloader_p7511.bin
Found 4 supported eMMC CID:
name = 'HAG2e' hex = 0x484147326505 [SKHYNIX]
eNAND_H26M52103FMR/16GB @FBGA169
eNAND_H9TQ17A8GTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17A8GTMCUR-KUM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KUM/16GB @BGA221
name = 'Q823MB' hex = 0x513832334D42 [SAMSUNG]
KMQ820013M-B419/16GB @BGA221
name = '016G70' hex = 0x303136473730 [TOSHIBA]
eSD_THGBMFG7C1LBAIL/16GB @FBGA153
name = 'Q72SMB' hex = 0x513732534D42 [SAMSUNG]
KMQ72000SM-B316/8GB @BGA221+LPDDR3 8Gb

Setting interface to EasyJtag2/E-Socket
Setting bus width to 8 Bit
Setting frequence to 42 MHz
EMMC Device Information :
EMMC CID: 150100524531424D4207B415C6B56357
EMMC CSD: D02701320F5903FFF6DBFFEF8E40400D
EMMC Manufacture : SAMSUNG , EMMC NAME: RE1BMB , HEX: 524531424D42 , S/N: B415C6B5 , rev. 0x07
EMMC Manufacture ID: 0x15 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 6/2016
EMMC ROM 1 (Main User Data) Capacity: 14910 MB (0003A3E00000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: RE1BMB_B415C6B5_20190705_195946.extcsd
EMMC Init completed.

Scanning soft partitions
GPT header is found and is valid
Partition: proinfo, [000000080000 - 000000380000], size: 000000300000 (3.00 MB)
Partition: nvram, [000000380000 - 000000880000], size: 000000500000 (5.00 MB)
Partition: protect1, [000000880000 - 000001280000], size: 000000A00000 (10.0 MB)
Partition: protect2, [000001280000 - 000001C80000], size: 000000A00000 (10.0 MB)
Partition: lk, [000001C80000 - 000001D00000], size: 000000080000 (512. KB)
Partition: para, [000001D00000 - 000001D80000], size: 000000080000 (512. KB)
Partition: boot, [000001D80000 - 000002D80000], size: 000001000000 (16.0 MB)
Partition: recovery, [000002D80000 - 000003D80000], size: 000001000000 (16.0 MB)
Partition: logo, [000003D80000 - 000004580000], size: 000000800000 (8.00 MB)
Partition: expdb, [000004580000 - 000004F80000], size: 000000A00000 (10.0 MB)
Partition: seccfg, [000004F80000 - 000005000000], size: 000000080000 (512. KB)
Partition: oemkeystore, [000005000000 - 000005200000], size: 000000200000 (2.00 MB)
Partition: secro, [000005200000 - 000005800000], size: 000000600000 (6.00 MB)
Partition: keystore, [000005800000 - 000006000000], size: 000000800000 (8.00 MB)
Partition: tee1, [000006000000 - 000006500000], size: 000000500000 (5.00 MB)
Partition: tee2, [000006500000 - 000006A00000], size: 000000500000 (5.00 MB)
Partition: frp, [000006A00000 - 000006B00000], size: 000000100000 (1.00 MB)
Partition: nvdata, [000006B00000 - 000008B00000], size: 000002000000 (32.0 MB)
Partition: metadata, [000008B00000 - 00000B000000], size: 000002500000 (37.0 MB)
Partition: system, [00000B000000 - 00008B000000], size: 000080000000 (2.00 GB)
Partition: cache, [00008B000000 - 000093000000], size: 000008000000 (128. MB)
Partition: userdata, [000093000000 - 0003A2D80000], size: 00030FD80000 (12.2 GB)
Partition: flashinfo, [0003A2D80000 - 0003A3D80000], size: 000001000000 (16.0 MB)
GPT header successfully parsed

Get firmware version

Firmware info not found

Setting interface to EasyJtag2/E-Socket
Setting bus width to 8 Bit
Setting frequence to 42 MHz
EMMC Device Information :
EMMC CID: 150100524531424D4207B415C6B56357
EMMC CSD: D02701320F5903FFF6DBFFEF8E40400D
EMMC Manufacture : SAMSUNG , EMMC NAME: RE1BMB , HEX: 524531424D42 , S/N: B415C6B5 , rev. 0x07
EMMC Manufacture ID: 0x15 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 6/2016
EMMC ROM 1 (Main User Data) Capacity: 14910 MB (0003A3E00000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: RE1BMB_B415C6B5_20190705_195956.extcsd
EMMC Init completed.

Opening file: MT6735M_Android_scatter.txt

The new format of scatter
config_version: V1.1.2
platform: MT6735M
preloader_p7511.bin
Found 4 supported eMMC CID:
name = 'HAG2e' hex = 0x484147326505 [SKHYNIX]
eNAND_H26M52103FMR/16GB @FBGA169
eNAND_H9TQ17A8GTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17A8GTMCUR-KUM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KUM/16GB @BGA221
name = 'Q823MB' hex = 0x513832334D42 [SAMSUNG]
KMQ820013M-B419/16GB @BGA221
name = '016G70' hex = 0x303136473730 [TOSHIBA]
eSD_THGBMFG7C1LBAIL/16GB @FBGA153
name = 'Q72SMB' hex = 0x513732534D42 [SAMSUNG]
KMQ72000SM-B316/8GB @BGA221+LPDDR3 8Gb

The size of the last section has been updated

Operation: Preloader parser

preloader_top6735m_35gu_l1.bin
Found 3 supported eMMC CID:
name = 'R31BAB' hex = 0x523331424142 [SAMSUNG]
name = 'HAG2e' hex = 0x484147326505 [SKHYNIX]
eNAND_H26M52103FMR/16GB @FBGA169
eNAND_H9TQ17A8GTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17A8GTMCUR-KUM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KUM/16GB @BGA221
name = 'RE1BMB' hex = 0x524531424D42 [SAMSUNG]

Setting interface to EasyJtag2/E-Socket
Setting bus width to 8 Bit
Setting frequence to 42 MHz
EMMC Device Information :
EMMC CID: 150100524531424D4207B415C6B56357
EMMC CSD: D02701320F5903FFF6DBFFEF8E40400D
EMMC Manufacture : SAMSUNG , EMMC NAME: RE1BMB , HEX: 524531424D42 , S/N: B415C6B5 , rev. 0x07
EMMC Manufacture ID: 0x15 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 6/2016
EMMC ROM 1 (Main User Data) Capacity: 14910 MB (0003A3E00000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: RE1BMB_B415C6B5_20190705_200113.extcsd
EMMC Init completed.

Opening file: MT6735M_Android_scatter.txt

The new format of scatter
config_version: V1.1.2
platform: MT6735M
preloader_top6735m_35gu_l1.bin
Found 3 supported eMMC CID:
name = 'R31BAB' hex = 0x523331424142 [SAMSUNG]
name = 'HAG2e' hex = 0x484147326505 [SKHYNIX]
eNAND_H26M52103FMR/16GB @FBGA169
eNAND_H9TQ17A8GTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17A8GTMCUR-KUM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KTM/16GB @BGA221
eNAND_H9TQ17ABJTMCUR-KUM/16GB @BGA221
name = 'RE1BMB' hex = 0x524531424D42 [SAMSUNG]

The size of the last section has been updated

Setting interface to EasyJtag2/E-Socket
Setting bus width to 8 Bit
Setting frequence to 42 MHz
EMMC Device Information :
EMMC CID: 150100524531424D4207B415C6B56357
EMMC CSD: D02701320F5903FFF6DBFFEF8E40400D
EMMC Manufacture : SAMSUNG , EMMC NAME: RE1BMB , HEX: 524531424D42 , S/N: B415C6B5 , rev. 0x07
EMMC Manufacture ID: 0x15 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 6/2016
EMMC ROM 1 (Main User Data) Capacity: 14910 MB (0003A3E00000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: RE1BMB_B415C6B5_20190705_200123.extcsd
EMMC Init completed.

Operation: Write by vendor (MediaTek)

Creating GPT-partitioninig
Writing PrimaryGPT at address: 000000000000
Writing BackupGPT at address: 0003A3DFBE00
GPT-partitioning done

Partition name: preloader
Filename: preloader_top6735m_35gu_l1.bin , Offset: 000000000000 , filesize: 124376 bytes
eMMC switching to ROM2
Erasing partition...
Writing partition...
Done writing partition. Write speed: 1494.59 KB/s
Partition name: lk
Filename: lk.bin , Offset: 000001C80000 , filesize: 415186 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 5116.36 KB/s
Partition name: boot
Filename: boot.img , Offset: 000001D80000 , filesize: 7073792 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 10484.50 KB/s
Partition name: recovery
Filename: recovery.img , Offset: 000002D80000 , filesize: 7811072 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 19297.58 KB/s
Partition name: logo
Filename: logo.bin , Offset: 000003D80000 , filesize: 1292810 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 12599.11 KB/s
Partition name: secro
Filename: secro.img , Offset: 000005200000 , filesize: 135168 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 4225.20 KB/s
Partition name: tee1
Filename: trustzone.bin , Offset: 000006000000 , filesize: 60416 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 3878.59 KB/s
Partition name: tee2
Filename: trustzone.bin , Offset: 000006500000 , filesize: 60416 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Done writing partition. Write speed: 3754.97 KB/s
Partition name: system
Filename: system.img , Offset: 00000B000000 , filesize: 2112320076 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Sparse image found v.1.0 Total chunks: 2436
Done writing partition. Write speed: 17803.44 KB/s
Partition name: cache
Filename: cache.img , Offset: 0000AB000000 , filesize: 6348948 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Sparse image found v.1.0 Total chunks: 10
Done writing partition. Write speed: 19297.69 KB/s
Partition name: userdata
Filename: userdata.img , Offset: 0000B3000000 , filesize: 20808176 bytes
eMMC switching to ROM1
Erasing partition...
Writing partition...
Sparse image found v.1.0 Total chunks: 39
Done writing partition. Write speed: 15871.71 KB/s

Writing DL_Info...
Writing DL_Info done

Writing eMMC Register ...
Reg: 179 Value: 0x48
Reg: 177 Value: 0x00
Reg: 162 Value: 0x01

All done time: [00:02:35:703]

Setting interface to EasyJtag2/E-Socket
Setting bus width to 8 Bit
Setting frequence to 42 MHz
EMMC Device Information :
EMMC CID: 150100524531424D4207B415C6B56357
EMMC CSD: D02701320F5903FFF6DBFFEF8E40400D
EMMC Manufacture : SAMSUNG , EMMC NAME: RE1BMB , HEX: 524531424D42 , S/N: B415C6B5 , rev. 0x07
EMMC Manufacture ID: 0x15 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 6/2016
EMMC ROM 1 (Main User Data) Capacity: 14910 MB (0003A3E00000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: RE1BMB_B415C6B5_20190705_200446.extcsd
EMMC Init completed.

Scanning soft partitions
GPT header is found and is valid
Partition: proinfo, [000000080000 - 000000380000], size: 000000300000 (3.00 MB)
Partition: nvram, [000000380000 - 000000880000], size: 000000500000 (5.00 MB)
Partition: protect1, [000000880000 - 000001280000], size: 000000A00000 (10.0 MB)
Partition: protect2, [000001280000 - 000001C80000], size: 000000A00000 (10.0 MB)
Partition: lk, [000001C80000 - 000001D00000], size: 000000080000 (512. KB)
Partition: para, [000001D00000 - 000001D80000], size: 000000080000 (512. KB)
Partition: boot, [000001D80000 - 000002D80000], size: 000001000000 (16.0 MB)
Partition: recovery, [000002D80000 - 000003D80000], size: 000001000000 (16.0 MB)
Partition: logo, [000003D80000 - 000004580000], size: 000000800000 (8.00 MB)
Partition: expdb, [000004580000 - 000004F80000], size: 000000A00000 (10.0 MB)
Partition: seccfg, [000004F80000 - 000005000000], size: 000000080000 (512. KB)
Partition: oemkeystore, [000005000000 - 000005200000], size: 000000200000 (2.00 MB)
Partition: secro, [000005200000 - 000005800000], size: 000000600000 (6.00 MB)
Partition: keystore, [000005800000 - 000006000000], size: 000000800000 (8.00 MB)
Partition: tee1, [000006000000 - 000006500000], size: 000000500000 (5.00 MB)
Partition: tee2, [000006500000 - 000006A00000], size: 000000500000 (5.00 MB)
Partition: frp, [000006A00000 - 000006B00000], size: 000000100000 (1.00 MB)
Partition: nvdata, [000006B00000 - 000008B00000], size: 000002000000 (32.0 MB)
Partition: metadata, [000008B00000 - 00000B000000], size: 000002500000 (37.0 MB)
Partition: system, [00000B000000 - 0000AB000000], size: 0000A0000000 (2.50 GB)
Partition: cache, [0000AB000000 - 0000B3000000], size: 000008000000 (128. MB)
Partition: userdata, [0000B3000000 - 0003A2D7BE00], size: 0002EFD7BE00 (11.7 GB)
Partition: flashinfo, [0003A2D7BE00 - 0003A3D7BE00], size: 000001000000 (16.0 MB)
GPT header successfully parsed

Get firmware version

Brand = Micromax
Manufacturer = Micromax
Device = Q413
Model = Micromax Q413
Phone platform = mt6735m
CPU Abi = armeabi-v7a
Mediatek platform = MT6735
Android release = 5.1
Firmware version = MMX_Q413_SW_V2.0.6_HW_V2.0.0_20160401
Firmware date = Thu Mar 10 03:19:30 CST 2016



WBR
Sarfraz Husain

Reactions: ranaawaiss

ferouzkassim

Active Member
Oct 11, 2018
43
29
Uganda
Skype
ferouz_kassim
another oppo a3s done wipe userdata and clear frp very fast in seconds and jobdone

Checking security ...
Z3X EasyJtag Software ver. 3.6.1.2
Loading eMMC GEN2 Firmware... IO: 2800 mV
Box S/N: 417A1E88471829FA, ,FW Ver.: 02.44
CMD Pullup Level:2120 mV
CMD Active Level:2685 mV
Box IO Level:2800 mV
CLK Rate:1000 kHz
Bus Width:1bit,SDR
HiPower mode is off!
---------- eMMC Device Information ----------

eMMC CID : 150100514536334D4203AE34DEA48523
eMMC CSD : D02701320F5903FFF6DBFFEF8E40400D
eMMC Manufacturer ID: 0015 , OEM ID: 0100
eMMC Date: 08/2018 Rev.0x3
eMMC NAME: QE63MB , S/N: 2922700452
eMMC NAME (HEX): 514536334D42
IC Name: Samsung , KMQE60013M-B318/16GB @BGA221
EMMC ROM1 (Main User Data) Capacity: 14910 MB , 0x1D1F000 pages , 0x3A3E00000 bytes
EMMC ROM2 (Boot Partition 1) Capacity: 4096 kB
EMMC ROM3 (Boot Partition 2) Capacity: 4096 kB
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 kB
EMMC RPMB is programmed and written 16175 times
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
EMMC Password Locked: No
Extended CSD rev 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG: 0x38] Boot from:ROM1 (Main User Area)
Boot bus config [177]: 0x00 , width 1bit , Partition config [179]: 0x38.
H/W reset function [RST_N_FUNCTION]: 0x01
High-capacity WP group size [HC_WP_GRP_SIZE: 0x00004000]
Partitioning Support [PARTITIONING_SUPPORT]: 0x07
Device support partitioning feature
Device can have enhanced tech.
Partitioning Setting [PARTITION_SETTING_COMPLETED]: 0x00
---------------------------------------------
Partition table scan:
GPT: present
Found valid GPT with protective MBR; using GPT.
Real (Hardware) Disk/Image size: 1D1F000 sectors 14.6 GiB
Soft (Partitioned) Disk/Image size: 1D1EFBC sectors 14.6 GiB
Logical sector size: 0x200 bytes
Disk identifier (GUID): 98101B32-BBE2-4BF2-A06E-2BB33D000C20
First usable sector: 34
Last usable sector: 30535646
Partition info successfully found
------ Android information ------
Detected LINUX(Android) CACHE : 0x001FB00000 (256.0MB)
Erasing...
Done.
Detected LINUX(Android) USERDATA : 0x0158000000 (9.184GB)
Erasing...
Done.
---------------------------------------------
Done.

Checking security ...
Running:Format FRP Partition...
Z3X EasyJtag Software ver. 3.6.1.2
Loading eMMC GEN2 Firmware... IO: 2800 mV
Box S/N: 417A1E88471829FA, ,FW Ver.: 02.44
CMD Pullup Level:2121 mV
CMD Active Level:2684 mV
Box IO Level:2800 mV
CLK Rate:1000 kHz
Bus Width:1bit,SDR
HiPower mode is off!
---------- eMMC Device Information ----------

eMMC CID : 150100514536334D4203AE34DEA48523
eMMC CSD : D02701320F5903FFF6DBFFEF8E40400D
eMMC Manufacturer ID: 0015 , OEM ID: 0100
eMMC Date: 08/2018 Rev.0x3
eMMC NAME: QE63MB , S/N: 2922700452
eMMC NAME (HEX): 514536334D42
IC Name: Samsung , KMQE60013M-B318/16GB @BGA221
EMMC ROM1 (Main User Data) Capacity: 14910 MB , 0x1D1F000 pages , 0x3A3E00000 bytes
EMMC ROM2 (Boot Partition 1) Capacity: 4096 kB
EMMC ROM3 (Boot Partition 2) Capacity: 4096 kB
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 kB
EMMC RPMB is programmed and written 16175 times
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
EMMC Password Locked: No
Extended CSD rev 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG: 0x38] Boot from:ROM1 (Main User Area)
Boot bus config [177]: 0x00 , width 1bit , Partition config [179]: 0x38.
H/W reset function [RST_N_FUNCTION]: 0x01
High-capacity WP group size [HC_WP_GRP_SIZE: 0x00004000]
Partitioning Support [PARTITIONING_SUPPORT]: 0x07
Device support partitioning feature
Device can have enhanced tech.
Partitioning Setting [PARTITION_SETTING_COMPLETED]: 0x00
---------------------------------------------
Partition table scan:
GPT: present
Found valid GPT with protective MBR; using GPT.
Real (Hardware) Disk/Image size: 1D1F000 sectors 14.6 GiB
Soft (Partitioned) Disk/Image size: 1D1EFBC sectors 14.6 GiB
Logical sector size: 0x200 bytes
Disk identifier (GUID): 98101B32-BBE2-4BF2-A06E-2BB33D000C20
First usable sector: 34
Last usable sector: 30535646
Partition info successfully found
Formatting FRP...
Detected LINUX(Android) CACHE : 0x001FB00000 (256.0MB) , formatting...
Done.
Detected LINUX(Android) CONFIG : 0x002FC80000 (32.0KB) formatting...
Done.
Detected LINUX(Android) USERDATA : 0x0158000000 (9.184GB) , formatting...
Done.
Done.
Done.

Reactions: Deepesh Sharma

ferouzkassim

Active Member
Oct 11, 2018
43
29
Uganda
Skype
ferouz_kassim
ANOTHER OPO A3S DONE

Z3X EasyJtag Software ver. 3.6.1.2
Loading eMMC GEN2 Firmware... IO: 2800 mV
Box S/N: 417A1E88471829FA, ,FW Ver.: 02.44
Warning: CMD Pullup Level (343 mV) too low , check cables etc.!
CMD Active Level:2662 mV
Box IO Level:2800 mV
CLK Rate:1000 kHz
Bus Width:1bit,SDR
HiPower mode is off!
---------- eMMC Device Information ----------

eMMC CID : 150100514536334D42060704D3ADA55D
eMMC CSD : D02701320F5903FFF6DBFFEF8E40400D
eMMC Manufacturer ID: 0015 , OEM ID: 0100
eMMC Date: 10/2018 Rev.0x6
eMMC NAME: QE63MB , S/N: 117756845
eMMC NAME (HEX): 514536334D42
IC Name: Samsung , KMQE60013M-B318/16GB @BGA221
EMMC ROM1 (Main User Data) Capacity: 14910 MB , 0x1D1F000 pages , 0x3A3E00000 bytes
EMMC ROM2 (Boot Partition 1) Capacity: 4096 kB
EMMC ROM3 (Boot Partition 2) Capacity: 4096 kB
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 kB
EMMC RPMB is programmed and written 70189 times
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
EMMC Password Locked: No
Extended CSD rev 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG: 0x38] Boot from:ROM1 (Main User Area)
Boot bus config [177]: 0x00 , width 1bit , Partition config [179]: 0x38.
H/W reset function [RST_N_FUNCTION]: 0x01
High-capacity WP group size [HC_WP_GRP_SIZE: 0x00004000]
Partitioning Support [PARTITIONING_SUPPORT]: 0x07
Device support partitioning feature
Device can have enhanced tech.
Partitioning Setting [PARTITION_SETTING_COMPLETED]: 0x00
---------------------------------------------
Backup saved: QE63MB_ 117756845_20190730_1300.extcsd
=============================================
Extended CSD rev 1.8 (MMC 5.1)
=============================================
Card Supported Command sets [S_CMD_SET: 0x01]
HPI Features [HPI_FEATURE: 0x01]:
implementation based on CMD13
Background operations support [BKOPS_SUPPORT: 0x01]
Max Packet Read Cmd [MAX_PACKED_READS: 0x3f]
Max Packet Write Cmd [MAX_PACKED_WRITES: 0x3f]
Data TAG support [DATA_TAG_SUPPORT: 0x01]
Data TAG Unit Size [TAG_UNIT_SIZE: 0x02]
Tag Resources Size [TAG_RES_SIZE: 0x00]
Context Management Capabilities [CONTEXT_CAPABILITIES: 0x05]
Large Unit Size [LARGE_UNIT_SIZE_M1: 0x07]
Extended partition attribute support [EXT_SUPPORT: 0x03]
Generic CMD6 Timer [GENERIC_CMD6_TIME: 0x0a]
Power off notification [POWER_OFF_LONG_TIME: 0x3c]
Cache Size [CACHE_SIZE] is 65536 KiB
------------------------- eMMC v5+ -------------------------
Supported modes [SUPPORTED_MODES: 0x03]
FFU features [FFU_FEATURES: 0x00]
Operation codes timeout [OPERATION_CODE_TIMEOUT: 0x00]
FFU Argument [FFU_ARG: 0xc7810000]
Number of FW sectors correctly programmed[NUM_OF_FW_SECT_CORR_PROG: 0]
Vendor proprietary health report:
[VENDOR_PROPRIETARY_HEALTH_REPORT[301]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[300]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[299]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[298]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[297]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[296]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[295]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[294]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[293]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[292]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[291]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[290]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[289]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[288]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[287]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[286]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[285]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[284]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[283]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[282]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[281]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[280]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[279]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[278]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[277]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[276]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[275]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[274]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[273]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[272]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[271]]:0x00
[VENDOR_PROPRIETARY_HEALTH_REPORT[270]]:0x00
_(Device life time estimation type B [DEVICE_LIFE_TIME_EST_TYP_B: 0x01]
i.e. 0% - 10% device life time used
_(Device life time estimation type B [DEVICE_LIFE_TIME_EST_TYP_A: 0x01]
i.e. 0% - 10% device life time used
Pre EOL information [PRE_EOL_INFO: 0x01]
i.e. Normal

Optimal read size [OPTIMAL_READ_SIZE: 0x00]
Optimal write size [OPTIMAL_WRITE_SIZE: 0x08]
Optimal trim unit size [OPTIMAL_TRIM_UNIT_SIZE: 0x01]
Device version [DEVICE_VERSION: 0x00 - 0x00]
Firmware version:
[FIRMWARE_VERSION[261]]: 0x00
[FIRMWARE_VERSION[260]]: 0x00
[FIRMWARE_VERSION[259]]: 0x00
[FIRMWARE_VERSION[258]]: 0x00
[FIRMWARE_VERSION[257]]: 0x00
[FIRMWARE_VERSION[256]]: 0x00
[FIRMWARE_VERSION[255]]: 0x00
[FIRMWARE_VERSION[254]]: 0x06
Power class for 200MHz, DDR at VCC= 3.6V [PWR_CL_DDR_200_360: 0x00]
-------------------------------------------------------------
Generic CMD6 Timer [GENERIC_CMD6_TIME: 0x0a]
Power off notification [POWER_OFF_LONG_TIME: 0x3c]
Cache Size [CACHE_SIZE] is 65536 KiB
Background operations status [BKOPS_STATUS: 0x00]
1st Initialisation Time after programmed sector [INI_TIMEOUT_AP: 0x1e]
Power class for 52MHz, DDR at 3.6V [PWR_CL_DDR_52_360: 0x00]
Power class for 52MHz, DDR at 1.95V [PWR_CL_DDR_52_195: 0x00]
Power class for 200MHz at 3.6V [PWR_CL_200_360: 0x00]
Power class for 200MHz, at 1.95V [PWR_CL_200_195: 0x00]
Minimum Performance for 8bit at 52MHz in DDR mode:
[MIN_PERF_DDR_W_8_52: 0x00]
[MIN_PERF_DDR_R_8_52: 0x00]
TRIM Multiplier [TRIM_MULT: 0x02]
Secure Feature support [SEC_FEATURE_SUPPORT: 0x55]
Boot Information [BOOT_INFO: 0x07]
Device supports alternative boot method
Device supports dual data rate during boot
Device supports high speed timing during boot
Boot partition size [BOOT_SIZE_MULTI: 0x20]
Access size [ACC_SIZE: 0x07]
High-capacity erase unit size [HC_ERASE_GRP_SIZE: 0x01]
High-capacity erase timeout [ERASE_TIMEOUT_MULT: 0x01]
Reliable write sector count [REL_WR_SEC_C: 0x01]
High-capacity W protect group size [HC_WP_GRP_SIZE: 0x10]
Sleep current (VCC) [S_C_VCC: 0x07]
Sleep current (VCCQ) [S_C_VCCQ: 0x07]
Sleep/awake timeout [S_A_TIMEOUT: 0x11]
Sector Count [SEC_COUNT: 0x01d1f000]
Minimum Write Performance for 8bit:
[MIN_PERF_W_8_52: 0x00]
[MIN_PERF_R_8_52: 0x00]
[MIN_PERF_W_8_26_4_52: 0x00]
[MIN_PERF_R_8_26_4_52: 0x00]
Minimum Write Performance for 4bit:
[MIN_PERF_W_4_26: 0x00]
[MIN_PERF_R_4_26: 0x00]
Power classes registers:
[PWR_CL_26_360: 0x00]
[PWR_CL_52_360: 0x00]
[PWR_CL_26_195: 0x00]
[PWR_CL_52_195: 0x00]
Partition switching timing [PARTITION_SWITCH_TIME: 0x02]
Out-of-interrupt busy timing [OUT_OF_INTERRUPT_TIME: 0x0a]
I/O Driver Strength [DRIVER_STRENGTH: 0x1f]
Card Type [CARD_TYPE: 0x57]
CSD structure version [CSD_STRUCTURE: 0x02]
Command set [CMD_SET: 0x00]
Command set revision [CMD_SET_REV: 0x00]
Power class [POWER_CLASS: 0x00]
High-speed interface timing [HS_TIMING: 0x00]
Erased memory content [ERASED_MEM_CONT: 0x00]
Boot configuration bytes [PARTITION_CONFIG: 0x38]
No access to boot partition
Boot config protection [BOOT_CONFIG_PROT: 0x00]
Boot bus Conditions [BOOT_BUS_CONDITIONS: 0x00]
High-density erase group definition [ERASE_GROUP_DEF: 0x00]
Boot write protection status registers [BOOT_WP_STATUS]: 0x00
Boot Area Write protection [BOOT_WP]: 0x00
Power ReadOnly locking: possible
Permanent ReadOnly locking: possible
Read Only lock status: not locked
User area write protection register [USER_WP]: 0x00
FW configuration [FW_CONFIG]: 0x00
RPMB Size [RPMB_SIZE_MULT]: 0x20
Write reliability setting register [WR_REL_SET]: 0x1f
Write reliability parameter register [WR_REL_PARAM]: 0x14
Enable background operations handshake [BKOPS_EN]: 0x02
H/W reset function [RST_N_FUNCTION]: 0x01
HPI management [HPI_MGMT]: 0x00
Partitioning Support [PARTITIONING_SUPPORT]: 0x07
Device support partitioning feature
Device can have enhanced tech.
Max Enhanced Area Size [MAX_ENH_SIZE_MULT]: 0x0003a3
Partitions attribute [PARTITIONS_ATTRIBUTE]: 0x00
Partitioning Setting [PARTITION_SETTING_COMPLETED]: 0x00
General Purpose Partition Size [GP_SIZE_MULT_4]: 0x000000
[GP_SIZE_MULT_3]: 0x000000
[GP_SIZE_MULT_2]: 0x000000
[GP_SIZE_MULT_1]: 0x000000
Enhanced User Data Area Size [ENH_SIZE_MULT]: 0x000000
Enhanced User Data Start Address [ENH_START_ADDR]: 0x000000
Bad Block Management mode [SEC_BAD_BLK_MGMNT]: 0x00
Periodic Wake-up [PERIODIC_WAKEUP]: 0x00
Program CID/CSD in DDR mode support [PROGRAM_CID_CSD_DDR_SUPPORT]: 0x01
Native sector size [NATIVE_SECTOR_SIZE]: 0x00
Sector size emulation [USE_NATIVE_SECTOR]: 0x00
Sector size [DATA_SECTOR_SIZE]: 0x00
1st initialization after disabling sector size emulation [INI_TIMEOUT_EMU]: 0x00
Class 6 commands control [CLASS_6_CTRL]: 0x00
Number of addressed group to be released[DYNCAP_NEEDED]: 0x00
Exception events control [EXCEPTION_EVENTS_CTRL]: 0x0000
Exception events status [EXCEPTION_EVENTS_STATUS]: 0x0000
Extended Partitions Attribute [EXT_PARTITIONS_ATTRIBUTE]: 0x0000
Packed command status [PACKED_COMMAND_STATUS]: 0x00
Packed command failure index [PACKED_FAILURE_INDEX]: 0x00
Power Off Notification [POWER_OFF_NOTIFICATION]: 0x00
Control to turn the Cache ON/OFF [CACHE_CTRL]: 0x00
Partition table scan:
GPT: present
Found valid GPT with protective MBR; using GPT.
Real (Hardware) Disk/Image size: 1D1F000 sectors 14.6 GiB
Soft (Partitioned) Disk/Image size: 1D1EFBC sectors 14.6 GiB
Logical sector size: 0x200 bytes
Disk identifier (GUID): 98101B32-BBE2-4BF2-A06E-2BB33D000C20
First usable sector: 34
Last usable sector: 30535646
Partition info successfully found
Found Data areas (firmware parts) count is: 65
---------------------------------------------
P0 (OPPODYCNVBK) [0x5000 0xa00000] Size: 10.0MB
P1 (OPPOSTANVBK) [0xa05000 0xa00000] Size: 10.0MB
P2 (MODEMST1) [0x1405000 0x180000] Size: 1.500MB
P3 (MODEMST2) [0x1585000 0x180000] Size: 1.500MB
P4 (PERSIST) [0x1705000 0x2000000] Size: 32.0MB
P5 (OPPORESERVE1) [0x3705000 0x800000] Size: 8.0MB
P6 (OPPORESERVE2) [0x3f05000 0x4000000] Size: 64.0MB
P7 (RESERVE_EXP1) [0x7f05000 0x200000] Size: 2.0MB
P8 (RESERVE_EXP2) [0x8105000 0x200000] Size: 2.0MB
P9 (FSC) [0x8305000 0x400] Size: 1.0KB
P10 (SSD) [0x8306000 0x2000] Size: 8.0KB
P11 (SBL1) [0x8308000 0x80000] Size: 512.0KB
P12 (RPM) [0x8388000 0x80000] Size: 512.0KB
P13 (TZ) [0x8408000 0x200000] Size: 2.0MB
P14 (DEVCFG) [0x8608000 0x40000] Size: 256.0KB
P15 (SBL1BAK) [0x8648000 0x80000] Size: 512.0KB
P16 (RPMBAK) [0x86c8000 0x80000] Size: 512.0KB
P17 (TZBAK) [0x8748000 0x200000] Size: 2.0MB
P18 (DEVCFGBAK) [0x8948000 0x40000] Size: 256.0KB
P19 (DSP) [0x8988000 0x1000000] Size: 16.0MB
P20 (DDR) [0xa000000 0x8000] Size: 32.0KB
P21 (FSG) [0xa008000 0x180000] Size: 1.500MB
P22 (SEC) [0xa188000 0x4000] Size: 16.0KB
P23 (ABOOT) [0xa18c000 0x100000] Size: 1.0MB
P24 (ABOOTBAK) [0xa28c000 0x100000] Size: 1.0MB
P25 (MODEM) [0xa38c000 0x8000000] Size: 128.0MB
P26 (DTBO) [0x1238c000 0x800000] Size: 8.0MB
P27 (VBMETA) [0x12b8c000 0x10000] Size: 64.0KB
P28 (BOOT) [0x12b9c000 0x4000000] Size: 64.0MB
P29 (RECOVERY) [0x16b9c000 0x4000000] Size: 64.0MB
P30 (DEVINFO) [0x1ab9c000 0x100000] Size: 1.0MB
P31 (SPLASH) [0x1b000000 0xb00000] Size: 11.0MB
P32 (LOGO) [0x1bb00000 0x2000000] Size: 32.0MB
P33 (DRIVER) [0x1db00000 0x2000000] Size: 32.0MB
P34 (CACHE) [0x1fb00000 0x10000000] Size: 256.0MB
P35 (MISC) [0x2fb00000 0x100000] Size: 1.0MB
P36 (KEYSTORE) [0x2fc00000 0x80000] Size: 512.0KB
P37 (CONFIG) [0x2fc80000 0x8000] Size: 32.0KB
P38 (OEM) [0x2fc88000 0x100000] Size: 1.0MB
P39 (LIMITS) [0x30000000 0x8000] Size: 32.0KB
P40 (MOTA) [0x30800000 0x80000] Size: 512.0KB
P41 (DIP) [0x30880000 0x100000] Size: 1.0MB
P42 (MDTP) [0x30980000 0x2000000] Size: 32.0MB
P43 (SYSCFG) [0x32980000 0x80000] Size: 512.0KB
P44 (MCFG) [0x32a00000 0x400000] Size: 4.0MB
P45 (LKSECAPP) [0x33000000 0x20000] Size: 128.0KB
P46 (CMNLIB) [0x33020000 0x100000] Size: 1.0MB
P47 (CMNLIB64) [0x33120000 0x100000] Size: 1.0MB
P48 (KEYMASTER) [0x33220000 0x100000] Size: 1.0MB
P49 (LKSECAPPBAK) [0x33320000 0x20000] Size: 128.0KB
P50 (CMNLIBBAK) [0x33340000 0x100000] Size: 1.0MB
P51 (CMNLIB64BAK) [0x33440000 0x100000] Size: 1.0MB
P52 (KEYMASTERBAK) [0x33540000 0x100000] Size: 1.0MB
P53 (APDP) [0x33800000 0x40000] Size: 256.0KB
P54 (MSADP) [0x33840000 0x40000] Size: 256.0KB
P55 (DPO) [0x33880000 0x2000] Size: 8.0KB
P56 (LOGDUMP) [0x33882000 0x4000000] Size: 64.0MB
P57 (VM-KYSTORE) [0x37882000 0x100000] Size: 1.0MB
P58 (VM-DATA) [0x37982000 0xa00000] Size: 10.0MB
P59 (HYP) [0x38800000 0x800000] Size: 8.0MB
P60 (VM-SYSTEM) [0x39000000 0x4000000] Size: 64.0MB
P61 (VM-LINUX) [0x3d000000 0x2000000] Size: 32.0MB
P62 (SYSTEM) [0x3f000000 0xd6900000] Size: 3.352GB
P63 (VENDOR) [0x115900000 0x41f60000] Size: 1.30GB
P64 (USERDATA) [0x158000000 0x24bdfbe00] Size: 9.184GB
------ Android information ------
Detected LINUX(Android) SYSTEM : 0x003F000000 (3.352GB)
Build ID: OPM1.171019.026
Release Base ID: 8.1.0
Architecture ABI: arm64-v8a
Device manufacturer: OPPO
Build Description: msm8953_64-user 8.1.0 OPM1.171019.026 eng.root.20190323.213841 release-keys
---------------------------------------------
Detected USERDATA USERDATA : 0x0158000000 (9.184GB)
Unable to mount USERDATA , code : 95
Done.

Selected eMMC Interface


---------- eMMC Device Information ----------

eMMC CID : 150100514536334D42060704D3ADA55D
eMMC CSD : D02701320F5903FFF6DBFFEF8E40400D
eMMC Manufacturer ID: 0015 , OEM ID: 0100
eMMC Date: 10/2018 Rev.0x6
eMMC NAME: QE63MB , S/N: 117756845
eMMC NAME (HEX): 514536334D42
IC Name: Samsung , KMQE60013M-B318/16GB @BGA221
EMMC ROM1 (Main User Data) Capacity: 14910 MB , 0x1D1F000 pages , 0x3A3E00000 bytes
EMMC ROM2 (Boot Partition 1) Capacity: 4096 kB
EMMC ROM3 (Boot Partition 2) Capacity: 4096 kB
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 kB
EMMC RPMB is programmed and written 70189 times
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
EMMC Password Locked: No
Extended CSD rev 1.8 (MMC 5.1)
Boot configuration [PARTITION_CONFIG: 0x38] Boot from:ROM1 (Main User Area)
Boot bus config [177]: 0x00 , width 1bit , Partition config [179]: 0x38.
H/W reset function [RST_N_FUNCTION]: 0x01
High-capacity WP group size [HC_WP_GRP_SIZE: 0x00004000]
Partitioning Support [PARTITIONING_SUPPORT]: 0x07
Device support partitioning feature
Device can have enhanced tech.
Partitioning Setting [PARTITION_SETTING_COMPLETED]: 0x00
---------------------------------------------
Partition table scan:
GPT: present
Found valid GPT with protective MBR; using GPT.
Real (Hardware) Disk/Image size: 1D1F000 sectors 14.6 GiB
Soft (Partitioned) Disk/Image size: 1D1EFBC sectors 14.6 GiB
Logical sector size: 0x200 bytes
Disk identifier (GUID): 98101B32-BBE2-4BF2-A06E-2BB33D000C20
First usable sector: 34
Last usable sector: 30535646
Partition info successfully found
------ Android information ------
Detected LINUX(Android) CACHE : 0x001FB00000 (256.0MB)
Erasing...
Done.
Detected LINUX(Android) USERDATA : 0x0158000000 (9.184GB)
Erasing...
Done.
---------------------------------------------
Done.





---------------------------------------------
Partition table scan:
GPT: present
Found valid GPT with protective MBR; using GPT.
Real (Hardware) Disk/Image size: 1D1F000 sectors 14.6 GiB
Soft (Partitioned) Disk/Image size: 1D1EFBC sectors 14.6 GiB
Logical sector size: 0x200 bytes
Disk identifier (GUID): 98101B32-BBE2-4BF2-A06E-2BB33D000C20
First usable sector: 34
Last usable sector: 30535646
Partition info successfully found
Formatting FRP...
Detected LINUX(Android) CACHE : 0x001FB00000 (256.0MB) , formatting...
Done.
Detected LINUX(Android) CONFIG : 0x002FC80000 (32.0KB) formatting...
Done.
Detected LINUX(Android) USERDATA : 0x0158000000 (9.184GB) , formatting...
Done.
Done.
Done.


ferouzkassim

Active Member
Oct 11, 2018
43
29
Uganda
Skype
ferouz_kassim
SAMSUNG G532F BOOT REPAIR DONE


eMMC_tool Suite ver. 1.6.2.0 (release date: 30.06.2019)
Microsoft Windows 7 (64 bit) build 7600 (6.1.7600.16385)

Looking for EasyJTAG box...
EasyJTAG API ver. 3307
EasyJTAG Box Serial = 417A1E88471829FA
Card Serial = AAF96E71
EasyJTAG Box Firmware = 2.44

Changelog:

30.06.2019 (ver 1.6.1.0)
Fix: Bugs that have been found through your crash report

Failed to connect to the server

Setting interface to EasyJtag2/ISP
Setting bus width to 1 Bit
Setting frequence to 1 MHz
CMD Pullup Level: 2806 mV
CMD Active Level: 2800 mV
EMMC Device Information :
EMMC CID: 90014A48384734759201C38364F935E3
EMMC CSD: D02701320F5903FFFFFFFFE78A40002B
EMMC Manufacture : SKHYNIX , EMMC NAME: H8G4u , HEX: 483847347500 , S/N: C38364F9 , rev. 0x01
EMMC Manufacture ID: 0x90 , OEM ID: 0x4A , Device Type: BGA (Discrete embedded) , Date: 3/2018
EMMC ROM 1 (Main User Data) Capacity: 7456 MB (0001D2000000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Maybe not clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.7 (MMC 5.0, MMC 5.01)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: H8G4u_C38364F9_20190809_143622.extcsd
EMMC Init completed.

Scanning soft partitions
GPT header is found and is valid
Partition: BOTA0, [000000400000 - 000000800000], size: 000000400000 (4.00 MB)
Partition: nvram, [000000800000 - 000001000000], size: 000000800000 (8.00 MB)
Partition: lk, [000001000000 - 000001200000], size: 000000200000 (2.00 MB)
Partition: BOTA1, [000001200000 - 000001400000], size: 000000200000 (2.00 MB)
Partition: secro, [000001400000 - 000001B00000], size: 000000700000 (7.00 MB)
Partition: seccfg, [000001B00000 - 000001B80000], size: 000000080000 (512. KB)
Partition: efuse, [000001B80000 - 000001C00000], size: 000000080000 (512. KB)
Partition: tee1, [000001C00000 - 000002200000], size: 000000600000 (6.00 MB)
Partition: BOTA2, [000002200000 - 000002800000], size: 000000600000 (6.00 MB)
Partition: EFS, [000002800000 - 000003000000], size: 000000800000 (8.00 MB)
Partition: nvdata, [000003000000 - 000005000000], size: 000002000000 (32.0 MB)
Partition: PARAM, [000005000000 - 000005800000], size: 000000800000 (8.00 MB)
Partition: recovery, [000005800000 - 000006800000], size: 000001000000 (16.0 MB)
Partition: boot, [000006800000 - 000007800000], size: 000001000000 (16.0 MB)
Partition: md1img, [000007800000 - 000009800000], size: 000002000000 (32.0 MB)
Partition: md1dsp, [000009800000 - 000009C00000], size: 000000400000 (4.00 MB)
Partition: keystore, [000009C00000 - 00000A400000], size: 000000800000 (8.00 MB)
Partition: omekeystore, [00000A400000 - 00000A780000], size: 000000380000 (3.50 MB)
Partition: proinfo, [00000A780000 - 00000AA00000], size: 000000280000 (2.50 MB)
Partition: para, [00000AA00000 - 00000AA80000], size: 000000080000 (512. KB)
Partition: PERSISTENT, [00000AA80000 - 00000AB00000], size: 000000080000 (512. KB)
Partition: STEADY, [00000AB00000 - 00000AC00000], size: 000000100000 (1.00 MB)
Partition: protect1, [00000AC00000 - 00000B400000], size: 000000800000 (8.00 MB)
Partition: protect2, [00000B400000 - 00000BC00000], size: 000000800000 (8.00 MB)
Partition: RESERVE2, [00000BC00000 - 00000C000000], size: 000000400000 (4.00 MB)
Partition: system, [00000C000000 - 0000CC800000], size: 0000C0800000 (3.01 GB)
Partition: cache, [0000CC800000 - 0000E5800000], size: 000019000000 (400. MB)
Partition: hidden, [0000E5800000 - 0000E9400000], size: 000003C00000 (60.0 MB)
Partition: userdata, [0000E9400000 - 0001D1C00000], size: 0000E8800000 (3.63 GB)
GPT header successfully parsed

Get firmware version

Brand = samsung
Manufacturer = samsung
Device = grandpplte
Model = SM-G532F
Phone platform = mt6737t
CPU Abi = armeabi-v7a
Mediatek platform = MT6737T
Android release = 6.0.1
Firmware version = MMB29T.G532FXWU1APJ1
Firmware date = Sat Oct 1 18:25:42 KST 2016

Setting interface to EasyJtag2/ISP
Setting bus width to 1 Bit
Setting frequence to 1 MHz
CMD Pullup Level: 3283 mV
CMD Active Level: 2843 mV
EMMC Device Information :
EMMC CID: 90014A48384734759201C38364F935E3
EMMC CSD: D02701320F5903FFFFFFFFE78A40002B
EMMC Manufacture : SKHYNIX , EMMC NAME: H8G4u , HEX: 483847347500 , S/N: C38364F9 , rev. 0x01
EMMC Manufacture ID: 0x90 , OEM ID: 0x4A , Device Type: BGA (Discrete embedded) , Date: 3/2018
EMMC ROM 1 (Main User Data) Capacity: 7456 MB (0001D2000000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Maybe not clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.7 (MMC 5.0, MMC 5.01)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: H8G4u_C38364F9_20190809_153546.extcsd
EMMC Init completed.

Scanning soft partitions
GPT header is found and is valid
Partition: BOTA0, [000000400000 - 000000800000], size: 000000400000 (4.00 MB)
Partition: NVRAM, [000000800000 - 000001000000], size: 000000800000 (8.00 MB)
Partition: LK, [000001000000 - 000001200000], size: 000000200000 (2.00 MB)
Partition: BOTA1, [000001200000 - 000001400000], size: 000000200000 (2.00 MB)
Partition: SECRO, [000001400000 - 000001B00000], size: 000000700000 (7.00 MB)
Partition: SECCFG, [000001B00000 - 000001B80000], size: 000000080000 (512. KB)
Partition: EFUSE, [000001B80000 - 000001C00000], size: 000000080000 (512. KB)
Partition: TEE1, [000001C00000 - 000002200000], size: 000000600000 (6.00 MB)
Partition: BOTA2, [000002200000 - 000002800000], size: 000000600000 (6.00 MB)
Partition: EFS, [000002800000 - 000003000000], size: 000000800000 (8.00 MB)
Partition: NVDATA, [000003000000 - 000005000000], size: 000002000000 (32.0 MB)
Partition: PARAM, [000005000000 - 000005800000], size: 000000800000 (8.00 MB)
Partition: RECOVERY, [000005800000 - 000006800000], size: 000001000000 (16.0 MB)
Partition: BOOT, [000006800000 - 000007800000], size: 000001000000 (16.0 MB)
Partition: MD1IMG, [000007800000 - 000009800000], size: 000002000000 (32.0 MB)
Partition: MD1DSP, [000009800000 - 000009C00000], size: 000000400000 (4.00 MB)
Partition: KEYSTORE, [000009C00000 - 00000A400000], size: 000000800000 (8.00 MB)
Partition: OMEKEYSTORE, [00000A400000 - 00000A780000], size: 000000380000 (3.50 MB)
Partition: PROINFO, [00000A780000 - 00000AA00000], size: 000000280000 (2.50 MB)
Partition: PARA, [00000AA00000 - 00000AA80000], size: 000000080000 (512. KB)
Partition: PERSISTENT, [00000AA80000 - 00000AB00000], size: 000000080000 (512. KB)
Partition: STEADY, [00000AB00000 - 00000AC00000], size: 000000100000 (1.00 MB)
Partition: PROTECT1, [00000AC00000 - 00000B400000], size: 000000800000 (8.00 MB)
Partition: PROTECT2, [00000B400000 - 00000BC00000], size: 000000800000 (8.00 MB)
Partition: RESERVE2, [00000BC00000 - 00000C000000], size: 000000400000 (4.00 MB)
Partition: SYSTEM, [00000C000000 - 0000CC800000], size: 0000C0800000 (3.01 GB)
Partition: CACHE, [0000CC800000 - 0000E5800000], size: 000019000000 (400. MB)
Partition: HIDDEN, [0000E5800000 - 0000E9400000], size: 000003C00000 (60.0 MB)
Partition: USERDATA, [0000E9400000 - 0001D1FFBE00], size: 0000E8BFBE00 (3.64 GB)
GPT header successfully parsed

Get firmware version

Firmware info not found

Setting interface to EasyJtag2/ISP
Setting bus width to 1 Bit
Setting frequence to 1 MHz
CMD Pullup Level: 3284 mV
CMD Active Level: 2844 mV
EMMC Device Information :
EMMC CID: 90014A48384734759201C38364F935E3
EMMC CSD: D02701320F5903FFFFFFFFE78A40002B
EMMC Manufacture : SKHYNIX , EMMC NAME: H8G4u , HEX: 483847347500 , S/N: C38364F9 , rev. 0x01
EMMC Manufacture ID: 0x90 , OEM ID: 0x4A , Device Type: BGA (Discrete embedded) , Date: 3/2018
EMMC ROM 1 (Main User Data) Capacity: 7456 MB (0001D2000000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Maybe not clean
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.7 (MMC 5.0, MMC 5.01)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x00 , width 1bit
H/W Reset Function [RST_N_FUNCTION]: 0x01, RST_n signal is permanently enabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: H8G4u_C38364F9_20190809_153604.extcsd
EMMC Init completed.

Operation: Writing all eMMC Regions...

Operation: Writing BootConfig ...
Reg: 179 Value: 0x48
Reg: 177 Value: 0x00
Reg: 162 Value: 0x01
Done

Writing to: ROM2 , start: 0x000000000000 , size: 0x000000400000
Filename: EMMC_QN16BB_ROM2_000000000000_000000400000.bin
eMMC switching to ROM2
Writing partition...
Done writing partition. Write speed: 59.72 KB/s

Writing to: ROM3 , start: 0x000000000000 , size: 0x000000400000
Filename: EMMC_QN16BB_ROM3_000000000000_000000400000.bin
eMMC switching to ROM3
Writing partition...
Done writing partition. Write speed: 59.82 KB/s

Writing to: ROM1 , start: 0x000000000000 , size: 0x00000C000000
Filename: EMMC_QN16BB_ROM1_000000000000_00000C000000.bin
eMMC switching to ROM1
Writing partition...
Done writing partition. Write speed: 119.75 KB/s

All done time: [00:29:41:413]


Deepesh Sharma

No Life Poster
Apr 4, 2017
1,732
2,467
India
Sonork ID
100.1614172
